KYOSHO - MINI-Z MR03 EVO SP CHASSIS SET (W-MM) 8500KV 32792B

Kyosho

185,75 €

32792B

Availability : Available

1 item in stock

KYOSHO - MINI-Z MR03 EVO SP CHASSIS SET (W-MM) 8500KV 32792B

Chassis set with separate receiver unit lets you use your own transmitter.

The existing MINI-Z is installed receiver, servo and ESC by 1 controlled PCB unit. But the new MR-03EVO Chassis Set has separate receiver as 1 unit. By purchasing and installing an optional receiver unit depending on applied transmitter, it allows for Kyosho (KT-18/EX-6/EX-6R/KT-531P/KT-432PT), KO Propo (EX-2/EX-RR) and Futaba (T7PX/T7XC) transmitters. It will be also applied with Sanwa transmitter in future. Further, by installing new CPU which control servo function only, it improves internal feedback of positioning control which is 11.2 times faster than existing VE PRO models. The newly developed control program realizes the best ever steering feeling in the MINI-Z history. The ESC also improves the response speed in maximum 100 times faster than existing VE PRO models. The included KYOSHO SPEED HOUSE XSPEED 85 (8500KV) brushless motor features a one-piece aluminum case that provides efficient heat dissipation for superior cooling. Unlike previous chassis sets, you can change to the brushed motor mode though the I.C.S manager to install an optional brushed motor. The I.C.S manager also allows more precise setting adjustments to be made. New advanced performance features in the MR-03EVO take the MINI-Z racing experience to the next level!

●First MINI-Z MR-03 Chassis Set that adopts separate ESC and receiver design.
●Includes new KYOSHO SPEED HOUSE XSPEED 85 brushless motor (8500KV).
●I.C.S manager features detailed steering and throttle parameter adjustment, as well as switching between brushless and brushed modes.
●Powered by independent CPUs for ESC and receiver, increased internal processing speed contributes to precision steering and throttle control.
The SP edition is equipped with nickel plated hex screws and an oil shock (MZW432) as standard. Also, the ball diff is specially finished with red anodizing. Furthermore, new upper arms with various caster angles (1 deg./2 deg./3 deg.) are included allowing wider setting range

Kit Contents :
● MR-03W-MM Factory assembled chassis with KYOSHO SPEED HOUSE XSPEED 85(8500KV) brushless motor
● Parts set for changing front tread
● 6T・7T・8T・9T Pinion gears
● Wheel wrench
● Tools for pinion gears
● Spare wheel nuts

Required for operation :
● Receiver unit
● Transmitter compatible with receiver unit
● Auto Scale Collection (body set, wheels, tires)
● AAA x 4 alkaline batteries or Ni-MH batteries for chassis
● Batteries for transmitter

  • Readyset KIT
  • Length 117.7mm
  • Width F:70〜75mm/R:70〜76mm
  • Height 35mm
  • Wheelbase 98.0mm (LL)
  • Tread (F/R) F:61.5〜66.5mm/R:61.5〜65mm
  • Motor SPEED HOUSE 12000KV
  • Transmission ratio 7.3、6.3、5.5、4.9:1
  • Weight 135g (approx.)
